Introducing Myles Kennedy’s first signature model. Known for his work in Alter Bridge, Slash and the Conspirators, and his own solo recordings, Kennedy is an accomplished guitarist who brings blues and jazz style to rock guitar playing. This new signature model mirrors Kennedy’s rock sensibilities with a nod to historic designs. While the aesthetic may have players hearing chicken pickin’ in their heads – and this guitar can certainly reach twang territory – it is made to play like a rock machine.

“This guitar captures the spirit of my favorite older instruments. With that said, since we developed this guitar, most of my vintage instruments rarely see the light of day,” said Kennedy.

The PRS Myles Kennedy signature guitar features a swamp ash body, a 22-fret, 25.5” scale length maple neck with maple fretboard, and two PRS Narrowfield MK pickups. The PRS Narrowfield MK pickups were carefully voiced to capture the courage of humbuckers and the spank of single coils. PRS Narrowfields provided the perfect starting point for this design, with their ability to deliver thick single-coil sounds without the hum. These pickups are paired with a 5-way blade switch and a push/pull tone control that acts as a preset tone roll- off, bringing down the higher frequencies on the treble pickup so you can dig in to the fullest.

“I watched Myles throughout his career alternate between humbucking and single coil sounds without giving anything up on either side. These pickups took us months to dial in, and I think they capture that balance that Myles mastered beautifully,” said Paul Reed Smith.

Other features include a PRS plate-style steel bridge, vintage-style locking tuners, bone nut, and Kennedy’s “Geometric Owl” logo from his “Ides of March” solo release, representing wisdom and adaptability.

“I feel like we managed to touch on the elusive quality that makes you want to play with this guitar. It beckons you to take it off the wall or out of the case and make music.” – Myles Kennedy

Featured Specifications


Body Construction Solidbody
Body Wood Swamp Ash
Top Carve Flat Top
Number of Frets 22
Scale Length 25.5"
Neck Wood Maple
Neck Construction Scarfed
Neck Shape Myles Kennedy
Neck Depth at the 1/2 Fret 57/64"
Neck Depth at the 12 1/2 Fret 31/32"
Neck Width at the Nut 1 41/64"
Neck Width at the Body 2 15/64"
Fretboard Wood Maple
Fretboard Radius 10"
Fretboard Inlay Birds
Headstock Logo Signature, Decal
Neck/Body Assembly
Neck/Body Assembly Type Bolt-On
Finish Type High-Gloss Nitro
Neck Finish Type Satin Nitro
Bridge PRS Plate Style, Steel
Tuners Vintage-Style, Locking
Hardware Type Nickel
Nut Bone
Treble Pickup Narrowfield MK
Bass Pickup Narrowfield MK
Controls Volume and Push/Pull Tone Control with 5-Way Blade Pickup Switch
Additional Info
Strings PRS Signature 10-46
Tuning Standard (6 String): E, A, D, G, B, E
Case Premium Gig Bag


Infographic showing switching positions for Myles Kennedy

Myles Kennedy - Controls Description

Position 1 (Switch Down): Treble / Humbucker

Position 2 (switch between down and Middle): Treble / Humbucker and Bass / Coil-Split

Position 3 (Switch middle): Treble / Humbucker and Bass / Humbkcer

Position 4 (Switch between up and middle): Treble / Coil-Split and Bass / Coil-Split

Position 5 (Switch Up): Bass / Humbucker

Push Pull Tone Knob: not your typical coil-split push/pull! this push/pull acts as a preset tone roll off for the treble pickup, bringing the higher frequencies down to slightly darken the tone.

active in positions 1-4.
