Custom 24 Piezo
24 Frets, Infinite Range of Tones
The Custom 24 Piezo is a 24-fret solidbody piezo-equipped guitar that effortlessly achieves classic humbucker tones and authentic acoustic sounds in one instrument. The added versatility of PRS’s patented tremolo gives musicians a new a unique tool to add to their lineup.
The Custom 24 Piezo has two output jacks, allowing guitarists to plug into their favorite electric or acoustic guitar amp or DI into a soundboard. By utilizing the separate blend control, the tone of the 85/15 pickups can also be combined with the piezo acoustic sounds through a single output. With a nearly infinite range of tones and the added versatility and reliability of PRS’s proprietary tremolo bridge, the Custom 24 Piezo is a perfect “go-to” guitar for players of all kinds.
For 2020, PRS has updated this model with TCI-tuned pickups and nitro over celluose (CAB) finish.
Pickup Switching Positions
Position One: Bridge humbucker
Position Two: Bridge humbucker with neck singlecoil, in parallel
Position Three: Bridge and neck humbuckers
Position Four: Neck singlecoil with bridge singlecoil, in parallel
Position Five: Neck humbucker
Gallery
Specifications
| Body | |
| Top Wood | Carved Figured Maple |
| Back Wood | Mahogany |
| Neck | |
| Number of Frets | 24 |
| Scale Length | 25" |
| Neck Wood | Mahogany |
| Neck Shape | Pattern Regular or Pattern Thin |
| Fretboard Wood | Rosewood |
| Fretboard Inlay | Birds |
| Neck/Body Assembly | |
| Neck/Body Assembly Type | Set |
| Hardware | |
| Bridge | PRS Patented Tremolo, Gen III |
| Tuners | PRS Phase III Locking |
| Hardware Type | Nickel |
| Electronics | |
| Treble Pickup | 85/15 |
| Bass Pickup | 85/15 |
| Controls | Volume and Tone Control with 5-Way Blade Pickup Switch and LR Baggs/PRS Piezo (3-Way Selector and Blend Knob) |
